EV2U-LOM1-RHCF | USB 2.0 2MP Fixed Focus Camera Module

Mã sản phẩm: Không áp dụng Tình trạng: Còn hàng

Giá Liên hệ

Model Name	EV2U-LOM1-RHCF
Module Type	USB 2.0 2MP Fixed Focus Camera Module
Resolution (Max.)	2MP
Frame Rate (Max. Resolution)	30fps
Output I/F	USB 2.0
Sensor	onsemi AR0246
Shutter	Rolling
Video Format	YUV422, MJPEG
Power Consumption	Approximate 0.6 W (MJPEG @Max. Resolution)
Operating Temperature	0°C ~ 70°C
Sensor Size	1/4”
Pixel Size	2.0µm
Chroma Type	Color
Lens Type	Fixed Focus (M12
Dimension (W x L x H/mm)	38 x 38 x 21.88 32 x 32 x 21.88 41.4 x 41.4 x 37.68 (Housing)
Lens FOV (D / H / V)	96° / 88° / 57°
OS Support	Windows / Linux / Android / macOS
Housing	Board Level, Housing
Features	HDR
Warranty	3 Years
